OM3 Multimode MTP-12 Trunk Cable, Aqua
OM3 multimode MTP-12 trunk cable offers high-speed, high-density connections for data centers, ideal for low-latency, short-distance transmissions up to 100 meters at 100Gbps.
$53.70
OM3 Multimode MTP-12 To MTP-12 Trunk Cable, Aqua
The OM3 multimode MTP-12 trunk cable is a high-performance fiber optic cable widely used in data centers and high-density network environments to support high-speed, short-distance data transmission. OM3 multimode fiber enables transmission over 300 meters at 10Gbps and 100 meters at 40Gbps and 100Gbps, making it ideal for high-bandwidth requirements. Its MTP-12 connector design uses an improved MTP multi-fiber connector, compatible with MPO, allowing for rapid connection of 12 fibers, enabling high-density, easy-to-plug connections that facilitate installation and maintenance.
As a trunk cable, it connects patch panels and equipment in data centers to form a high-speed backbone link, significantly reducing cabling space and management complexity. The OM3 MTP-12 trunk cable is an ideal choice for modern data centers aiming for high-density, low-latency network connections.
Specifications
| Connector A | US Conec MTP | Connector B | US Conec MTP |
| Fiber Mode | OM3 50/125μm | Wavelength | 850/1300nm |
| Glass Fiber | Corning ClearCurve® Multimode Fiber | Minimum Bend Radius | 7.5mm |
| Trunk Diameter | 3.0mm | Polish Type | UPC to UPC |
| Insertion Loss (dB) | ≤0.35dB | Return Loss (dB) | ≥20dB |
| Operating Temperature | -10 to 70°C (14 to 158℉) | Storage Temperature | -40 To 80°C (-40 To 176℉) |
Features
Pre-terminated MTP Technology-Polarity
The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.
Three Jacket MaterialsThe differences between OFNP, PVC, LSZH jackets.
|
